Description
The Crave provides modern luxury at an affordable price. These Direct Vent gas fireplaces feature multiple upgrade options that let you accent your style and personalize your look. It’s an easy choice. Modern luxury, backed by the #1 preferred brand by builders.
What's Included
- Fireplace Unit (NG)
- RC400 Remote Control
- Junction Box
- Ceramic Glass
- Gas Flex Connector
- Battery Backup
- IntelliFire Touch Ignition System
Not Included
- 2x Front (Required to Complete)
- Crushed Glass Media (Required to Complete)
- Gas Conversion Kit
- Log Set
- Light Kit
- Light Baffle Kit
- Liner Kit
- Heat Management
- Other Controls/Remotes/Switches
Features
- Available in 36", 48", 60", and 72" models. Define your design with four sizes—in single sided or see-through configurations—and multiple customization options.
- Industry leading end-to-end flame technology
- Battery Backup - Ensures you always have a reliable source of warmth even with a winter power outage.
- Direct Vent Technology - Removes any fumes or combustion exhaust efficiently and effectively from your home.
- IntelliFire Touch® - Offers you a touchscreen remote control or wireless wall switch to fit your life.
- Two-Sided Viewing - Expands your viewing of the fire from two rooms at once and adds multiple design possibilities.
Venting Notes
- If using a power vent, must order AUX module (2326-150) and wire harness (SRV2326-152)
- Requires 8" DVP pipe. Must have a 18" minimum vertical vent before attaching a 90° elbow to unit. See Venting section.
- Approved for use with PVLP-SLP, PVI-SLP-B and PVV-SLP with power vent wire harness and IFT-RC400 remote (order separately). See venting section of manual.
Specifications
| Item Number | CRAVE6048ST-C | |
| Brand Name |
|
|
| Series | Crave See-Through | |
| Model | Crave48 ST Rev B 48" See-Through Gas Fireplace - DV | |
| Fuel Type | Natural Gas Liquid Propane using Conversion Kit |
|
| Viewing Area | 47-1/2" x 12-1/2" | |
| BTU/hr Input | 21,000 - 40,000 (NG) 19,500 - 36,000 (LP) |
Technical Specifications
| Actual (Unit) | Framing | |
| Front Width (A) | 58" (1473mm) | 60-1/4" (1530mm) |
| Back Width (B) | 58" (1473mm) | 60-1/4" (1530mm) |
| Height (C) | 41-3/4" (1060mm) | 42" (1067mm) |
| Depth (D) | 17-1/8" (435mm) | 17" (432mm) |
Documents & Files
- Crave Series - Product Brochure
- Installation Manual
- Owner's Manual
- Service Parts
- Architect Guide
- Revit BIM
- Light Kit Instructions
-
Heat-Out-Gas Instructions
- Heat-Zone-Gas Instructions
- Heat-Zone-Gas Adapter Instructions
-
Passive Heat Front Discharge Instructions
-
Passive Heat Side Discharge Instructions
- Passive Heat Trim Kit Instructions
- Passive Heat Kit Instructions
- PVLP-SLP - Power Vent Low Profile Instructions
Fronts and Doors
Clean Face Trim
Four Square 36
Illusion 36
Fire Bed Colors
Other Accessories
Remote Touchscreen
Wall Switch
Wall Switch Kit with battery backup
Wi-Fi Module for IntelliFire App
