Heatilator Crave Direct Vent Gas Fireplace - CRAVE4836-C

Roll over image to zoom in Click on image to zoom

Heatilator Crave Direct Vent Gas Fireplace - CRAVE4836-C

Heatilator

Title: Default Title

Variant

Price:

$3,769.00

Quantity:

Share this product

The Crave provides modern luxury at an affordable price. All of the essentials for a complete modern design are available in both single-sided and see-through models. Multiple upgrade options also let you accent your style and personalize your look. These affordable fireplaces are truly the best option on the market, providing modern luxury, backed by the #1 preferred brand by builders.

What's Included

Fireplace Unit (NG)
RC400 Remote Control
Junction Box
Ceramic Glass
Gas Flex Connector
Battery Backup
IntelliFire Touch Ignition System

Not Included

Front (Required to Complete)
Crushed Glass Media (Required to Complete)
Gas Conversion Kit
Log Set
Light Kit
Liner Kit
Heat Management
Other Controls/Remotes/Switches

Features

Available in 36", 48", 60", and 72" models. Define your design with four sizes—in single sided or see-through configurations—and multiple customization options.
Industry leading end-to-end flame technology
Battery Backup - Ensures you always have a reliable source of warmth even with a winter power outage.
Direct Vent Technology - Uses outside air for combustion, expelling 100% of the combustion exhaust and by-products.
IntelliFire Touch® - Offers you a touchscreen remote control or wireless wall switch to fit your life.

Venting Notes

If using a power vent, must order AUX module (2326-150) and wire harness (SRV2326-152).
Requires 8" DVP pipe. Must have a 18" minimum vertical vent before attaching a 90Â° elbow to unit. See Venting section.
Approved for use with PVLP-SLP, PVI-SLP-B and PVV-SLP with power vent wire harness and IFT-RC400 remote (order separately). See venting section of manual.

Specifications

Item Number	CRAVE4836-C
Brand Name	Heatilator
Series	Crave
Model	Crave 36 Rev C 36" Gas Fireplace - DV
Fuel Type	Natural Gas Liquid Propane using Conversion Kit
Viewing Area	35-1/2" x 12-1/2"
BTU/hr Input	17,000 - 30,000 (NG) 15,500 - 29,000 (LP)

Technical Specifications

	Actual (Unit)	Framing
Front Width (A)	46-3/16" (1173mm)	48-1/4" (1226mm)
Back Width (B)	46-3/16" (1173mm)	48-1/4" (1226mm)
Height (C)	41-3/4" (1060mm)	42" (1067mm)
Depth (D)	17-1/8" (435mm)	18-1/4" (464mm)
