Always Stay Charged and Prepared
Description
SOLIX F3800 Power Station FEATURES
- Designed with plug-and-play home backup capability. (Accessories sold separately.)
- 6,000W, 120V/240V split-phase output in one unit for power-hungry appliances.
- 3.84kWh - 26.9kWh expandable capacity with up to 6 expansion batteries (Anker SOLIX BP3800).
- Scaling up to 12kW (53.8kWh) for extended power outages.
- 2,400W solar input, allowing for a charge of 0 to 80% in just 1.5 hours by sunlight.
- Equipped with NEMA 14-50 and L14-30 outlet to directly charge your EV and RV.
- Monitor energy intelligently via the app. Connect with Bluetooth and Wi-Fi.
- Long-Lasting LFP batteries and 5-year hassle-free warranty.
- Industry-leading high-quality components ensuring 10 years of product life.
Anker SOLIX F3800 SPECIFICATIONS
| Capacity | 3,840Wh |
| AC Input |
120V~15A (3H Max), 12A (Continuous), 60Hz
|
| AC Input Power (Charging) | 1,800W Max |
| AC Input Power (Bypass Mode) | 1,440W Max |
| Solar Panel Input |
2400W (1200W*2) MPPT1: 11-28V⎓ 10A; 28V-60V⎓ 27A Max MPPT2: 11-28V⎓ 10A; 28V-60V⎓ 27A Max (firmware 2.0.9+)
|
| Car Charger Output | 12V⎓10A |
| Home Panel Power Port |
3,800W Max (AC Input), 6,000W Max (AC Output), 120V/240V
|
| AC Output Power (Total) | 6,000W Max |
| AC Output |
120V~20A Max, 60Hz, 2,400W Max
|
| AC Output (NEMA 14-50/L14-30) |
120V/240V~25A Max, 60Hz, 6,000W Max
|
| USB-A Output |
5V⎓2.4A (12W Max per Port)
|
| USB-C Output |
5V⎓3A/9V⎓3A/15V⎓3A/20V⎓3A/20V⎓5A (100W Max per Port)
|
| UPS | 20ms |
| Discharging Temperature |
-4°F - 104°F / -20°C - 40°C
|
| Charging Temperature |
32°F - 104°F / 0°C - 40°C
|
| Size |
27.6 × 15.3 × 15.6 in / 70.2 × 38.8 × 39.5 cm
|
