Cozy up to the best of living
Create an inviting place where the best moments begin with the big, bold and comfy Caliber gas fireplace. Gather 'round dancing flames and warm up with generous heat. Even run your fireplace with a smart speaker. With on-trend styling to fit your look, it will be your favorite spot in the home.
- Available in 36" and 42" widths, offering two models with added features and upgrades.
- Up to 44,000 BTUs to warm medium to larger spaces.
- Variable speed fan disperses heat throughout the room; standard on Caliber nXt
- Dynamic Thermostat - Tapers flames with rising temps to maintain comfort level.
- Battery Backup - Ensures you always have a reliable source of warmth even with a winter power outage.
- Direct Vent Technology - Removes any fumes or combustion exhaust efficiently and effectively from your home.
- IntelliFire Touch® - Offers you a touchscreen remote control or wireless wall switch to fit your life.
Venting Notes
- Requires DVP pipe. See Venting section.
- Approved for use with SLP pipe. Note: Restrictions apply. See installation manual for venting specifications.
- Approved for use with PVLP-SLP, PVI-SLP-B and PVV-SLP with power vent wire harness and IFT-RC400 remote (order separately). See venting section of manual.
What's Included
- Fireplace Unit (LP)
- 12' Control Wire
- Manual Gas Shut-off Valve
- 6 Ceramic Fiber Logs
- Junction Box
- Gas Flex Connector
- Tempered Glass
- Glowing Embers, Lava Rock, and Vermiculite
- Battery Backup
- IntelliFire Touch Ignition System
Not Included
- Front (Required to Complete)
- Liner Kit
- Refractory Upgrade
- Fan
- Heat Management
- Other Controls/Remotes/Switche
| Item Number |
CD4236IFTLR |
| Brand Name |
Heatilator |
| Series |
Caliber
|
| Model |
Caliber 36 36" Gas Fireplace - DV |
| Fuel Type |
Liquid Propane |
| Viewing Area |
35" x 24-1/8" |
| BTU/hr Input |
16,000 - 29,000 |
Technical Specifications
|
Actual (Unit) |
Framing |
| Front Width (A) |
41" (1041mm) |
42" (1067mm) |
| Back Width (B) |
28-1/2" (724mm) |
42" (1067mm) |
| Height (C) |
39-7/8" (1013mm) |
40-1/8" (1019mm) |
| Depth (D) |
21" (533mm) |
22" (559mm) |
Installation Manuals
